Price Each:
$155

Local Unit

• Compatible with a computer or HDTV video source with HDMI output.
• One female HDMI connector.
  • Not compatible with nVidia Quadro FX series video cards.
• One female RJ45 port for sending high definition video/audio signals.
• One female RJ45 port for sending DDC signal.
• HDCP 1.3 compliant.

Remote Unit

• One female HDMI connector for display.
• One female RJ45 port for receiving high definition video/audio signals.
• One female RJ45 port for receiving DDC signal.
• Supports HDTV resolutions to 1080i and computer resolutions to 1920x1080.

Power

• Local unit: powered from remote unit through CAT5e/6 cable.
• Remote unit: 110 or 220 VAC at 50 or 60 Hz via AC adapter.(US AC adapter included.)
• Power consumption:
  • Local unit: powered from remote unit.
  • Remote unit: 5W

Cables

• Use HDMI-xx-MM cable to connect an HDMI source or display.
• Use DVI-HDMI-xx-MM cable to connect a DVI source or display.
• Use CAT5e/6 solid straight through cable for TIA/EIA-568B wiring terminated with standard RJ45 connectors.
• Cables not included.

Environmental

• Operating temperature: 5 to 130°F (-15 to 55°C).
• Storage temperature: -20 to 140°F (-30 to 60°C).
• Operating and Storage Relative Humidity: 5 to 90% non-condensing RH.

Dimensions

• WxDxH (in): 1.8x3.3x0.9

Regulatory Approvals

• CE, FCC, RoHS

MTBF

• 20,000 hrs.

Warranty

• Two years.
